Feature
● Max temperature RT～1750℃ with HRE resistance wire/SiC heater/MoSi2 heater options
● 4sides heating with excellent temperature uniformity
● Touch‑screen operation for easy understanding. Supports temperature curves, data logging and data export.
● One-click up and down
|
Model |
SL2-18TP |
|
Dimensions: Internal D x W x H (mm) |
Customized as per user's request to load samples |
|
Max.temperature(℃) |
1800 |
|
Working temperature(℃) |
1750 |
|
Volume (litres) |
Customized as per user's request based on loading |
|
Power(KW) |
220~600V support to suit for user's on-site voltage/phase |
|
Thermocouple type |
K/S/B optional to meet different temperature's request |
|
Heating element |
HRE resistance wire/Kanthal resistance wire/SiC heater/MoSi2 heater optional to meet user's temperature processing requirement |
|
Temp.Precision |
±1℃ |
|
Heating rate |
0-20℃/minute adjustable |
|
Chamber material |
Using advanced high-quality alumina microcrystalline fiber material or ceramic foam refractory chamber |
|
Furnace structure |
Double-layer air-cooled structure,Bottom loading |
|
Temperature controller |
Intelligent PID temperature control instrument, multiple program segments, SSR control, PID parameter self-tuning function; program temperature rise, program heat preservation, program cooling,curve and datasheet support,Data export to U disk support,USB port support |
|
Certification: CE, ISO9001, SGS ect, more than 30 patent certifications |
|
|
Warranty: One-year warranty (excluding wearing parts) and long-term technical support |
|
|
Support OEM/ODM |
|
Standard Accessories
Thermal gloves | Crucible Tongs | Thermocouple | User Manual |Tools |
