Vacuum Atmosphere Furnace

Your Professional Vacuum Atmosphere Furnace Manufacturers


Xinkyo Company was founded in 2005 by professional materials researchers. Its founder studied at Peking University and is a leading manufacturer of high-temperature experimental equipment and new materials research laboratory equipment. This enables us to provide high-quality, low-cost high-temperature equipment for materials research and development laboratories. Thanks to its excellent design, affordable prices, and customer service, Xinkyo is committed to becoming the world leader in materials science research for high-temperature equipment.




First 12 Last

Why Choose Us

Advanced Equipment
Main production equipment: CNC punching machines, CNC bending machines, CNC engraving machines, high-temperature oven CNC lathes, lying machines, gantry milling, machining centers, sheet metal, laser cutting machines, CNC punching machines, bending machines, self capacitive welding machines, argon arc welding machines, laser welding, sandblasting machines, automatic paint baking rooms.



Wide Range of Applications
The products are mainly used in ceramics, powder metallurgy, 3D printing, new material research and development, crystal materials, metal heat treatment, glass, negative electrode materials for new energy lithium batteries, magnetic materials, etc.



Wide Market
XinKyo Furnace's annual export sales revenue is more than 50 million, with North American markets (such as the United States, Canada, Mexico, etc.) accounting for 30% and European markets (such as France, Spain, Germany,etc) accounting for about 20%; 15% in Southeast Asia (Japan, Korea, Thailand, Malaysia, Singapore, India, etc) and 10% in the Russian market; 10% in the Middle East (Saudi Arabia, UAE, ect ), 5% in the Australian market, and the remaining 10%.



Our Service
Provide comprehensive pre-sales, in sales, and after-sales services, including technical support, Track usage and give positive feedback. Rapid response within 24 hours.



Main Functions And Characteristics Of Vacuum Atmosphere Furnace





• Control accuracy: +1℃ furnace temperature uniformity: +1℃ (depending on the size of the heating chamber).



• Easy to operate, programmable, PID self-tuning, automatic heating, automatic heat preservation, automatic cooling, without duty; can be equipped with computer communication through the operation of electric furnace (start electric furnace, stop electric furnace, pause heating, set heating curve, heating curve storage, history curve, etc.). Free software details are as follows: computer control system.



• The heating rate is fast (the heating rate can be adjusted from 1℃/h to 40℃/min).



• Energy saving (the furnace is made of imported fibers, high temperature resistance, heat and cold resistance).



• The furnace body is exquisitely sprayed, corrosion-resistant, acid-resistant and alkali-resistant, and the air-cooled furnace wall temperature is close to room temperature in isolation from the furnace body.



• Dual-circuit protection (over-temperature, over-voltage, over-current, segment couple, power failure, etc.).



• Furnace materials imported refractories, good thermal insulation, high temperature resistance, rapid cold and heat resistance.



• Temperature category: 1200℃ 1400℃ 1600℃ 1700℃ 1800℃.



• Furnace body sealing and water-cooling structure: Seals: Seals are made of silicone rubber rings (260℃-350℃Celsius). Cooling structure: double shell, air-cooled + water-cooled.



Common Applications



Atmosphere Box Furnace
  • Material Processing

    Sintering, brazing, and annealing metals in vacuum furnaces.

  • Electronics

    Semiconductor manufacturing and thin-film deposition.

  • Food Preservation

    Extends shelf life by removing oxygen.

  • Research

    Laboratories use vacuum environments for experiments requiring minimal interference.



Material and Surface Quality



Clean and Bright Surfaces

The vacuum environment eliminates impurities, resulting in clean, bright, and transmutation-free surfaces.

No Oxidation

High-temperature heating in a vacuum prevents oxidation, preserving the integrity and appearance of materials.



Technical Parameters



Model SA2-16-14TP(touch screen temperature controller version and extra 1 temperature measurement device and trays included).
Max.design(℃) 1400℃,suggested continious using 1300℃.
Internal dimensions: D x W x H (mm) 400*300*300MM(36Litre).
Gas inlet and outlet Support(2ports and 2witches corronspondingly control).
Gas pipe connection Needle valve quick connector
Vacuum pressure gauge -0.1Mpa to 0.15Mpa measurement(positive pressure need to not more than 0.02Mpa and pressure afjustment switch included).
Power(KW) 16
Voltage(V) 380V in stock,220V or 440V can be customized.
Thermocouple type S type
Heating rate 0-20C/min
Temp.Precision ±1℃
Furnace structure Double-layer air-cooled structure, surface temperature is less than 60℃.
Furnace chamber material 1600 Type latest alumina ceramic fiber refractory chamber.
Heating element SiC heating element,Two-sided heating.
Temperature controller Yudian brand,Touch screen, 10X50 temperature and time program, PID control, curve and data sheet visualization, data can be exported to USB disk for storage and archiving, and can be viewed, analyzed and printed on the computer; ±1℃ accuracy. Over-temperature protection, broken alarm, data memory function.
Extra 1temperature measurement Included,purpose for over temperature automatic power off,double protection(optional).
Trays SiC plate(optional)
Standard Accessories Thermal gloves | Crucible Tongs | Thermocouple | Furnace Door Block | User Manual |Tools |
Certification CE, ISO9001:2015, SGS.
Warranty One-year warranty (excluding wearing parts) and long-term technical support.



Packing



productcate-955-236



Standard fumigated wooden crates for European exports.

Flexible solutions (PE film/special packaging) for container optimization.

Accommodates custom packaging requests.



Delivery



Package Size

200.00cm * 240.00cm * 260.00cm

Package Gross Weight

300.000kg



FAQ



Q: What about the delivery time?

A: Normally within 15 days after receiving your payment or basedon order quantity and production schedule.

Q: What about the guarantee period?

A: The guarantee period is 12 months.

Q: Are you atmosphere furnace manufacturer?

A: Yes, We keep a large stock of them all year round.

Q: What kind terms of payment can be accepted?

A: L/C, T/T, Western Union, Paypal, Trade Assurance, etc.

Q: Are you a manufacturer or trading company?

A: The MoQ is 1 pcs.

Q: What is the difference between a vacuum furnace and an atmosphere furnace?

A: The difference between the atmosphere furnace and the vacuum furnace also lies in the high thermal efficiency of the vacuum heat treatment furnace, which can achieve rapid leveling and cooling, can be completed without oxidation, decarburization, non-carburization, can remove phosphorus chips from the surface of the.
