Products Description
Agon atmosphere furnace is an atmosphere protective heat treatment equipment that can pass argon, nitrogen and other protective gases. Agon atmosphere furnaceadopts a double-layer air-cooled structure, the surface temperature is close to room temperature, high-quality alumina ceramic fiberboard, and the furnace door is equipped with a sealing ring with good sealing to ensure the airtightness of the furnace.
Agon atmosphere furnace mainly provides high-temperature heat treatment environment for laboratories of universities, research institutes, factories and enterprises, and can be used in new materials fields such as metal materials, ceramic materials, nanomaterials, semiconductor materials, etc.
Technical parameters
Nitrogen atmosphere furnace
| Model | SA2-1-12TP | SA2-212TP | SA2-6-12TP | SA2-9-12TP |
|
Max.design(℃) |
1200 | 1200 | 1200 | 1200 |
|
Internal dimensions: D x W x H (mm) |
100*100*100 | 200*150*150 | 300*200*200 | 400*300*300 |
| Power(KW) | 1KW | 2KW | 6KW | 9KW |
| Voltage(V) | 220V 1P | 220V 1P | 220V 1P | 380V 3P |
| Volume (litres) | 1 | 4.5 | 12 | 16 |
|
External dimensions: Dx W x H (mm) |
490*547*769mm | 630*605*870 | 740*645*955mm | 875*805*1060mm |
| Thermocouple type | K | |||
| Max.vacuum | -0.1Mpa | |||
| Heating rate | 0-20C/min | |||
| Heating element | High quality HRE resistance wire | |||
| Temp.Precision | ±1℃ | |||
| Furnace structure | Double-layer air-cooled structure, surface temperature is less than 60℃ | |||
| Temperature controller | Intelligent PID temperature control instrument,30 program segments,SSR control, PID parameter self-tuning function; program temperature rise, program heat preservation, program cooling | |||
| Atmosphere | Various inert gases such as oxygen, carbon monoxide, nitrogen, argon, etc. | |||
| Gas Control | The air inlet can be equipped with one or more air inlets, each of which is equipped with a ball valve and connected to a vacuum gauge. The air outlet is connected to an outlet hole, and all holes are equipped with ball valves. The maximum positive pressure in the furnace does not exceed 0.02Mpa | |||
| Vacuum system | Single-stage rotary vane pump Maximum limit 5Pa Optional double-stage rotary vane pump |
|||
| Sealing method | The furnace door adopts the overall surface grinding and milling, and the silicone strip is embedded in the seal, which has strong sealing performance and is easy to open and close. | |||
|
Standard Accessories vacuum pump|Thermal gloves | Crucible Tongs | Thermocouple | Furnace Door Block | User Manual |Tools | |
||||
| Certification: CE, ISO, SGS ect, more than 30 patent certifications | ||||
| Warranty: One-year warranty (excluding wearing parts) and long-term technical support | ||||
| Optional:
Different chamber size for your choose; 50 segment program for choose LCD touch screen control for choose RS485/USB port to connect computer for choose. Working temeprature,Max.vacuum for choose |
||||
Product details
Argon atmosphere furnace
The hand wheel nut rotates, the furnace door seals more firmly
High quality heating element with polycrystalline insulation chamber furnace
Equipped with vacuum port, air inlet, pressure regulating valve, pressure gauge and other configurations to achieve multi-function
LCD highly intelligent instrument,30-segment program with PID control
Float flow meter (30-300ml/min)
Control gas flow rate
Vacuum system
Can meet the normal vacuum state in the furnace
Product Application
Be used in a wide range of Argon atmosphere furnace
Laboratory
Metal
Ceramic
Electronics
Chemical
Glass
