Products Description
1800℃ High temperature muffle furnace is the highest design temperature of the box-type furnace type, which can meet the multi-process needs of customers. The temperature control accuracy is ±1°C. The double-layer insulation material has a high insulation effect. 1800℃ High temperature muffle furnace has automatic temperature control and is suitable for new applications. Experimental research in materials development, special materials, building materials and other fields.
Feature
● Max temperature RT～1800℃
● 1800 Type Mosi2 heating element, heating on both sides
● 50 segments programmable with PID control
● Integrated dual-circuit protection, over-temperature and burnout protection
|
Model |
SX2-2-18TP |
SX2-4-18TP |
SX2-9-18TP |
SX2-16-18TP |
|
Dimensions: Internal D x W x H (mm) |
100*100*100 |
200*150*150 |
300*200*200 |
400*300*300 |
|
Dimensions: External D x W x H (mm) |
425*320*568 |
570*470*815 |
670*530*906.2 |
770*620*1055 |
|
Max.temperature(℃) |
1800 |
1800 |
1800 |
1800 |
|
Working temperature(℃) |
0-1700 |
|||
|
Volume (litres) |
1 |
4.5 |
12 |
36 |
|
Power(KW) |
2 |
4 |
9 |
16 |
|
Voltage(V) |
220 1P |
220 1P |
380 2P |
380 2P |
|
Thermocouple type |
B |
|||
|
Heating element |
Mosi2 heating element |
|||
|
Temp.Precision |
±1℃ |
|||
|
Heating rate |
0-10℃/min free adjustment |
|||
|
Chamber material |
Using advanced high-quality alumina microcrystalline fiber material |
|||
|
Furnace structure |
Double-layer air-cooled structure, surface temperature is less than 60℃ |
|||
|
Certification: CE, ISO, SGS ect, more than 30 patent certifications |
||||
|
Warranty: One-year warranty (excluding wearing parts) and long-term technical support |
||||
|
Support OEM/ODM |
||||
Optional
Different chamber size for your choose;
50 segment program for choose
LCD touch screen control for choose
RS485/USB port to connect computer for choose.
Chimney, door opening method, air intake hole, observation window, etc. are optional.
