High vacuum brazed tube furnace Products Description
The High vacuum Brazed tube furnace with a diameter of 250mm uses large-diameter heating tubes, which can process a large number of samples. It has a double-layer air-cooled structure, low furnace shell temperature, and uses high-quality iron chromium aluminum alloy as the heating element. Equipped with a high vacuum diffusion pump set to achieve high vacuum inside the furnace. It targets small materials that are brazed and sintered in high vacuum environments.High vacuum brazed tube furnace is also suitable for rare earth materials, catalyst materials, magnetic materials, lithium battery positive and negative electrode materials (lithium manganate, ternary, phosphoric acid), and can also be used in glass, bioceramics, graphene, lithium battery positive and negative materials, crystal annealing, LED luminous materials and other fields. It can be used for heat treatment, sintering, deposition coating, ash measurement and other occasions of samples under atmosphere protection.
Feature of High vacuum brazed tube furnace
1. High quality HRE resistance wire,fast heating rate,Good furnace temperature uniformity
2.High quality alumina ceramic fiber,Good thermal insulation effect
3.LED program temperature control, temperature control accuracy ±1 degree
4.Stainless steel sealing flange, corrosion resistance, high temperature resistance, good sealing
Technical parameters
250mm diameter vacuum tube furnace
| Model | SK2-12TP |
| Max.design(℃) | 1200 |
| Working temperature(℃) | 0-1100 |
|
Tube diameter(mm) D x W x H (mm) |
250mm |
| Heating zone length(mm) | 440mm or customized |
| Voltage(V) | 220V 1phase |
| Thermocouple type | K |
| Max.vacuum | 10-3Pa |
| Heating rate | 0-20C/min |
| Temp.Precision | ±1℃ |
| Furnace structure | Double-layer air-cooled structure, surface temperature is less than 60℃ |
| Furnace chamber material | 1430℃ grade Alumina ceramic firber refractory chamber |
| Inlet gas/Atmosphere | It can be filled with various protective or destructive gases,Inert gases, mixed gases, nitrogen, oxygen, etc,The maximum positive pressure does not exceed 0.02Mpa |
| Gas control | It has an air inlet and an air extraction hole with a ball valve, which can be connected to a vacuum pump and a flow meter can be added. |
| Sealing way | Adopt 304 stainless steel flange, with easy loading and unloading, oxidation resistance, acid and alkali resistance, double seal, ensure the sealing |
| Temperature control security | The electric furnace adopts integrated circuit, module control, double circuit protection (partial temperature protection, ultra-high temperature protection, coupling protection, overcurrent protection, overpressure protection and other protection functions) to make the electric furnace work stable and reliable, safe. |
| Vacuum system |
High vacuum diffusion pump set max.vacuum:5*10-3Pa(cold state) KF25 quick flange, bellows, resistance gauge, ionization gauge, vacuum gauge and other parts. |
| Cooling system | Adopt circulating water chiller cooling pump group, high efficiency and energy saving, cooling capacity 2400w, temperature control accuracy can reach ±0.5℃ |
| Temperature controller | Adopting advanced temperature instruments, 30 segment programs can be set, with high temperature control accuracy,SSR control, PID parameter self-tuning function; program temperature rise, program heat preservation, program cooling |
|
Standard Accessories Quartz tube|SS flange|vacuum pump|Thermal gloves | Crucible Tongs | Thermocouple | User Manual |Tools | |
||||
| Certification: CE, ISO, SGS ect, more than 30 patent certifications | ||||
| Warranty: One-year warranty (excluding wearing parts) and long-term technical support |
Product details
250mm diameter vacuum tube furnace
Product Application
Be used in a wide range of250mm diameter vacuum tube furnace
Laboratory
Metal
Ceramic
Electronics
Chemical
Glass
