Products Description of Muffle furnace 1400C
The muffle furnace 1400 ℃ is a high-capacity heat treatment electric furnace. It adopts a double-layer air-cooled structure with a lower surface temperature. The furnace body is heated with silicon carbon rods, and the large muffle furnace adopts a two-sided heating design, making the heating elements easy to replace. This furnace has uniform heating function and uses high-quality alumina ceramic fiber board insulation material, which is suitable for batch processing of materials such as metals, ceramics, and glass.
Features of Muffle furnace 1400C
1. Continuous working.temperature 1300℃
2.Double furnace frame with cooling fan.
3. Intelligently programmable controller,PID automatic control 30segments
Technical parameters
Large muffle furnace
| Model | SX2-4-14TP |
| Max.design(℃) | 1400 |
|
Internal dimensions: D x W x H (mm) |
200*150*150MM |
| Power(KW) | 4 |
| Voltage(V) | 220V,single phase. |
| Volume (litres) | 4.5L |
| Thermocouple type | S |
| Heating rate | 0-20C/min |
| Temp.Precision | ±1℃ |
| Furnace structure | Double-layer air-cooled structure, surface temperature is less than 60℃ |
| Furnace chamber material | 1600 Type higher furnace cleanliness than ceramic fiber materials. |
| Heating method | Two-sided heating, using high-quality SIC heaters |
| Temperature controller | Adopting advanced instruments, multiple multi-stage programs can be set, with high temperature control accuracy,SSR control, PID parameter self-tuning function; program temperature rise, program heat preservation, program cooling |
|
Standard Accessories Thermal gloves | Crucible Tongs | Thermocouple | Furnace Door Block | User Manual |Tools | |
||||
| Certification: CE, ISO9001:2016, SGS ect, more than 30 patent certifications | ||||
| Warranty: One-year warranty (excluding wearing parts) and long-term technical support |
Product details
Product Application
Be used in a wide range of Large muffle furnace
Laboratory
Metal
Ceramic
Electronics
Chemical
Glass
